Single-Extension Concealed Drawer Slides
Our single extension concealed drawer slides are designed for wooden drawers requiring compact installation, smooth movement, and reliable soft-close performance. This two section concealed slide series is suitable for furniture applications where partial drawer extension and stable daily use are required.
This single extension concealed drawer slide series is developed for wooden drawers that require a compact undermount solution with reliable soft-close function. The two section structure supports smooth and stable movement, while the integrated damping system ensures gentle and quiet closing. Available with pin fixing or 1D handle options, this series is suitable for kitchen cabinets, bathroom cabinets, bedroom furniture, and utility storage applications.
Product Overview
This single extension concealed drawer slide series is developed for wooden drawers that require a compact undermount solution with reliable soft-close function. The two section structure supports smooth and stable movement, while the integrated damping system ensures gentle and quiet closing. Available with pin fixing or 1D handle options, this series is suitable for kitchen cabinets, bathroom cabinets, bedroom furniture, and utility storage applications.
Single extension design
Push-open mechanism
Compact two section structure
Handleless application
Pin and 1D handle options
Up to 25 kg load capacity
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Single Extension Push-Open Concealed Drawer Slides |
| Function | Push-Open |
| Installation Type | Concealed Bottom Mounted |
| Application | Wooden Drawers |
| Load Capacity | 25 kg |
| Cycle Test | Over 30,000 cycles |
| Drawer Side Panel Thickness | 16 mm / 19 mm |
| Nominal Lengths | 250 / 300 / 350 / 400 / 450 / 500 mm |
| Fixing Options | Pin / 1D Handle |
| Versions | Full Size / Short Size |
| Front Gap Requirement | 4 mm |
Available Sizes & Models
| Model | Front Fixing Option |
|---|---|
| BTR-A / MBTR-A | With Pin |
| BJR-A / MBJR-A | With 1D Handle |
Available Options
To match different furniture structures and installation requirements, this concealed drawer slide system is available with multiple front locking and adjustment options.
Pin Type
alternative fixing option for different drawer designs
1D Handle
practical and economical adjustment option
Installation & Dimensions
Detailed installation dimensions are available for 16mm and 19mm drawer side panels. The AJH-SW-A series is designed for concealed bottom mounting and requires cabinet and drawer dimensions to match the specified nominal length.
Product Dimensions
Installation Drilling
Drawer Requirements
Adjustment Guide
